² Characteristics:
l Grinding disc with holes shall provide high impact and shear to grinding media and reduce dead area significantly
l Material of grinding disc and spacer: S.S.304/carbon steel/PU/wearable nylon
l Material of grinding chamber: S.S.304/carbon steel /PU/wearable nylon
l Gland packings are adopted to reduce volatilization of solvent in grinding media.
l Cooling jacket outside grinding chamber is adopted to cool down grinding media.
l Thermometer at product outlet is adopted to detect temperature of output products.
l Continuous production
² Applications:
l Wet grinding of paint, pesticide, non-mineral filler, etc.
² Technical data:
Model | SB-20 | SB-40 | SB-80 |
Chamber volume(L) | 20 | 40 | 80 |
Main motor power(KW) | 11 | 18.5 | 30 |
Dispersing shaft speed(r.p.m) | 1320 | 1020 | 830 |
Output capacity(L/h) | 150-400 | 300-700 | 500-1200 |
Grinding media | Φ2.0-3.5mm Glass beads |
Material feeding | By diaphragm pump/gear pump |
