Dispersing disc: saw-tooth shape S.S.304
Grinding head: wearable nylon
Disperse/grind liquid-solid materials effectively
Material of wetted parts: S.S.304/S.S.420/S.S.201
Rack lifting mode: by hand
Easy to clean and change color
Wet dispersing/grinding of paint, dye, pesticide, printing ink, papermaking, adhesive, etc.
Model
SDF-0.4
Volume of tank(L)
3
Motor power(KW)
0.4
Dispersing blade (mm)
Ф50,Φ60
Grinding head
Ф45,Ф60
Grinding media
Φ1.5-2.0mm Glass beads
Lifting stroke(mm)
230
Shaft speed(r.p.m.)
0-8000
Outline measure(mm)
445*420*600
N.W.(Kg)
40
G.W. (Kg)
50
Package dimension (mm)
710*480*710
