² Characteristics:
l Grinding disc with holes shall provide high impact and shear to grinding media and reduce dead area significantly
l Material of grinding disc and spacer: S.S.304/carbon steel/PU/wearable nylon
l Material of grinding chamber: S.S.304/carbon steel /PU/wearable nylon
l Cooling jacket outside grinding chamber is adopted to cool down grinding media.
l Thermometer at product outlet is adopted to detect temperature of output products.
l Continuous production
l Easy to clean
² Application:
l Wet grinding of paint, pesticide, non-mineral filler, etc.
² Technical data:
Model | SK-10 | SK-20 | SK-40 | SK-80 |
Chamber volume (L) | 10 | 20 | 40 | 80 |
Main motor power (KW) | 5.5 | 11 | 18.5 | 30 |
Main shaft speed r.p.m) | 1440 | 1320 | 1020 | 830 |
Output capacity (L/H) | 80-200 | 150-400 | 300-700 | 500-1200 |
Grinding media | Φ2.0-3.5mm Glass beads | |||
Material feeding | By diaphragm pump/gear pump | |||
